SURREY, BC - JANUARY 27 – JANUARY 31, 2025
EDMONTON, AB – FEBRUARY 3 – FEBRUARY 7, 2025
CALGARY, AB – FEBRUARY 10 – FEBRUARY 14, 2025
REGINA, AB – FEBRUARY 24 – FEBRUARY 28, 2025
Overview of TBC basic entities, importing files, view filter and project explorer, data selection, exporting data to site positioning devices and machines, import and export to “OTHER” CAD software, transfer SMART data from one VCE to another VCE file.
Elevating lines and contours, creating surfaces from field data for incremental pay quantities, working with SPJ file, setting up a 3D site, using edit command, using and understanding project cleanup command.
Creating multiple concentric offsets with create side slope command, using variable offset line command to create ditch and ridge lines, additional control of the surface properties and use of linestring command.
Importing and georeferencing PDF’s, extracting linework from vector PDF’s, using multiple "over-lapping" PDF images for take offs and data prep, create ONE non-overlapping picture from multiple images.
Setup corridor/road with horizontal and vertical alignment profile and templates, combining multiple corridor models at intersections, elevating contours from CAD for proposed surface, creating 3D break lines for ditches and ridges to control surfaces, creating a composite surface for an entire subdivision.
